Extractor | Advanced Extraction Technology
Advanced Extraction Technology

Industrial Extractor

High-capacity continuous solvent extraction systems engineered to maximize oil yield and minimize solvent loss in edible oil plants.

Engineering Focus

Maximizing Yield. Preventing Losses.

In solvent extraction, every drop of oil left in the meal and every vapor of hexane lost impacts your profitability. Our extractors are built to push residual oil down to < 1% safely and efficiently.

sync

Counter-Current Extraction

Our extractors utilize a highly efficient multi-stage, counter-current washing process. Pure solvent meets the leanest seed cake at the discharge end, ensuring maximum penetration and deep extraction of the last remaining oil molecules.

security

Vapor-Tight Operational Safety

Hexane is highly volatile. Our extractor casings are precision-welded and structurally reinforced to operate under slight negative pressure, guaranteeing zero solvent vapor leaks into the factory atmosphere.

Integrated sight glasses and explosion-proof (ATEX) lighting allow operators to safely monitor the internal miscella flow and percolation rate in real-time.

Flagship Equipment

Continuous Extractor

Extractor Technology
Percolation Design

Deep Bed Extraction

The key to a high-yield extraction is maintaining the perfect bed height of the prepared seed/cake. Our extractors feature an adjustable speed drive that allows operators to tune the residence time precisely based on the material's porosity.

High-volume miscella circulation pumps spray the solvent evenly over the bed, ensuring thorough penetration without flooding the compartments.

  • check_circle Self-cleaning wedge wire screens prevent choking.
  • check_circle Variable frequency drives (VFD) for precision speed control.
  • check_circle Multi-stage spraying system for uniform solvent distribution.
Material Excellence

Heavy-Duty Structural Integrity

Continuous extractors handle massive loads of saturated meal. The main casing and hoppers are fabricated from heavy-gauge mild steel or stainless steel, braced with structural ribs to eliminate flexing or vibration.

The internal chain and sprocket mechanism is forged from high-tensile alloy steel, engineered to pull the heavy bed of material smoothly 24/7 without snapping or stretching.

Extractor Build Quality

Operational Capabilities

Proven Extraction Efficiency

<1% Residual Oil

Extracts maximum oil, leaving less than 1% residual oil in the discharged meal.

1500+ TPD Capacity

Built for massive scale continuous processing in global oil seed plants.

100% Vapor Sealed

Negative pressure design ensures completely leak-free hexane processing.

Technical Specifications

Engineered Features

filter_alt

Wedge Wire Screens

add

The extraction bed is supported by highly durable, self-cleaning stainless steel wedge wire screens, preventing blinding and ensuring flawless miscella percolation.

speed

Variable Speed Drive (VSD)

add

The main chain drive is controlled by an advanced VFD, allowing operators to instantly adjust the bed speed and residence time depending on the raw material being processed.

water_drop

Multi-Stage Miscella Pumps

add

Equipped with a series of high-capacity centrifugal pumps that continuously recirculate the miscella over the seed bed, ensuring maximum solvent saturation and washing.

sensors

Automated Level Control

add

The feed hopper is equipped with smart level sensors that automatically control the rotary valve, maintaining a perfect vapor seal and consistent material input.

settings

Heavy-Duty Chain Drive

add

Forged alloy steel chains and precision-machined sprockets ensure the internal band moves massive tonnage flawlessly without stretching, breaking, or jamming.

visibility

Sight Glass & Illumination

add

Multiple ATEX-certified illuminated sight glasses are strategically placed along the casing, allowing operators to safely monitor the extraction sprays and bed movement.

Implementation Protocol

How We Work

Our engineering teams design every extractor to match your specific seed prep capacity, ensuring perfect percolation and maximum oil recovery.

science

Feed Analysis

We evaluate the porosity, flaking thickness, and oil content of your prepared seed cake to determine the precise length and bed depth required for the extractor.

architecture

Flow & Residence Design

Our engineers calculate the optimum solvent-to-meal ratio, designing the multi-stage spray zones to guarantee optimal counter-current washing without flooding.

precision_manufacturing

Fabrication & Hydro-Testing

The casing is welded, thoroughly leak-tested, and assembled with the heavy-duty drive chain. Once cleared, it is shipped and integrated into your extraction plant.

Case Studies & Endorsements

Industry Testimonials

format_quote
star star star star star

"Before installing this continuous extractor, we were struggling with high residual oil and constant chain stretching issues. Upgrading to this system solved both immediately. Our residual oil dropped to consistently below 1%, and the heavy-duty drive hasn't required adjustment in 18 months."

RK

Mr. Rajesh K.

Plant Head, Global Soy Extractions

Featured Video Case Study

Video Thumbnail
play_arrow

Mr. Osman Ansari

Managing Director, Ansari Oil Mills

Support & Information

Frequently Asked Questions

What types of seeds can the extractor process? add
The extractor is highly versatile. Assuming proper seed preparation (flaking/expanding), it can process Soybean, Sunflower, Rapeseed/Canola, Cottonseed, Groundnut, and Rice Bran.
What is counter-current extraction? add
It's a process where the fresh, pure solvent enters at the discharge end (where the meal has the least oil), and flows backward against the material flow. This guarantees maximum oil extraction efficiency.
How do you prevent hexane leaks? add
The entire main casing is heavily welded and pressure-tested. Additionally, the system operates under a slight negative pressure, meaning if a seal were ever compromised, air gets pulled in, rather than hexane leaking out.
What capacities are available? add
We manufacture custom extractors ranging from 50 Tons Per Day (TPD) for boutique or specialized operations, all the way up to massive 1500+ TPD continuous plants.
How do you control the extraction time? add
The main drive motor is connected to a Variable Frequency Drive (VFD). This allows the operator to instantly speed up or slow down the internal band, perfectly tuning the residence (extraction) time.
What kind of screens are used inside? add
We use heavy-duty stainless steel wedge wire screens. Their unique V-shaped profile makes them self-cleaning, preventing fine meal particles from blinding the screen and halting percolation.
